AE86 OEM SEATS
AE86 GTS (USA Model) Seat Information
Submitted and complied by Richard White (quickly becoming THE GURU)
The following information is for those interested in restoring or repairing their GTS Seat. Many of the parts are now becoming increasing difficult to get at a reasonable price. Though a replacement high performance racing seat is superior in strength, it may not match your budget or the look that would fit in the Toyota museum. I have tried to copy the information as best I can, but please beware that mistakes can and do occur. Please consult our Toyota parts department for independent verification and notice the last two digits. That is the color. And again this list is not comprehensive for all models of AE86s.
71061S
Cover Sub-Assy, Front Seat Back, Upper RH
|
Prod.
Date |
Model |
Description |
Part
Number |
Qty. |
|
8408-8508 |
AE86.. GTS |
Deep Maroon |
71061-12010-02 |
2 |
|
8408-8508 |
AE86.. GTS |
Grey |
71061-12010-03 |
2 |
71062S
Cover Sub-Assy, Front Seat Back, Upper LH
|
Prod.
Date |
Model |
Description |
Part
Number |
Qty. |
|
8408-8508 |
AE86.. GTS |
Deep Maroon |
71062-12010-02 |
2 |
|
8408-8508 |
AE86.. GTS |
Grey |
71062-12010-03 |
2 |
71071S
Cover, Front Seat Cushion, RH
|
Prod.
Date |
Model |
Description |
Part
Number |
Qty. |
|
8408-8508 |
AE86.. GTS |
FB, Deep Maroon |
71071-1E490-02 |
1 |
|
8408-8508 |
AE86.. GTS |
FB, Grey |
71071-1E490-03 |
1 |
|
8508-8608 |
AE86.. GTS |
FB, Black |
71071-1E780-01 |
1 |
|
8508-8608 |
AE86.. GTS |
FB, Blue |
71071-1E780-04 |
1 |
|
8608- |
AE86.. GTS |
FB, W/ Sports Seat, Black |
71071-1E781-01 |
1 |
|
8608- |
AE86.. GTS |
FB, W/ Sports Seat, Blue |
71071-1E781-04 |
1 |
|
8608- |
AE86.. GTS |
FB, Black |
71071-1H060-01 |
1 |
|
8608- |
AE86.. GTS |
FB, Blue |
71071-1H060-04 |
1 |
71072S Cover, Front Seat Cushion, LH
|
Prod.
Date |
Model |
Description |
Part
Number |
Qty. |
|
8408-8508 |
AE86.. GTS |
FB, Deep Maroon |
71072-1E140-02 |
1 |
|
8408-8508 |
AE86.. GTS |
FB, Grey |
71072-1E140-03 |
1 |
|
8508-8608 |
AE86.. GTS |
FB, Black |
71072-1E200-01 |
1 |
|
8508-8608 |
AE86.. GTS |
FB, Blue |
71072-1E200-04 |
1 |
|
8608- |
AE86.. GTS |
FB, W/ Sports Seat, Black |
71072-1E201-01 |
1 |
|
8608- |
AE86.. GTS |
FB, W/ Sports Seat, Blue |
71072-1E201-04 |
1 |
|
8608- |
AE86.. GTS |
FB, Black |
71072-1E300-01 |
1 |
|
8608- |
AE86.. GTS |
FB, Blue |
71072-1E300-04 |
1 |
71073S
Cover, Front Seat Back, RH
|
Prod.
Date |
Model |
Description |
Part
Number |
Qty. |
|
8408-8508 |
AE86.. GTS |
FB, Deep Maroon |
71073-1E690-02 |
1 |
|
8408-8508 |
AE86.. GTS |
FB, Grey |
71073-1E690-03 |
1 |
|
8508-8608 |
AE86.. GTS |
FB, Grey |
71073-1E880-03 |
1 |
|
8508-8608 |
AE86.. GTS |
FB, Blue |
71073-1E880-04 |
1 |
|
8608- |
AE86.. GTS |
FB, W/ Sports Seat, Black |
71073-1E881-01 |
1 |
|
8608- |
AE86.. GTS |
FB, W/ Sports Seat, Blue |
71073-1E881-04 |
1 |
|
8608- |
AE86.. GTS |
FB, Black |
71073-1H140-01 |
1 |
|
8608- |
AE86.. GTS |
FB, Blue |
71073-1H140-04 |
1 |
71074S
Cover, Front Seat Back, LH
|
Prod.
Date |
Model |
Description |
Part
Number |
Qty. |
|
8408-8508 |
AE86.. GTS |
FB, Deep Maroon |
71073-1E690-02 |
1 |
|
8408-8508 |
AE86.. GTS |
FB, Grey |
71073-1E690-03 |
1 |
|
8508-8608 |
AE86.. GTS |
FB, Grey |
71074-1A830-03 |
1 |
|
8508-8608 |
AE86.. GTS |
FB, Blue |
71074-1A830-04 |
1 |
|
8608- |
AE86.. GTS |
FB, W/ Sports Seat, Black |
71074-1A831-01 |
1 |
|
8608- |
AE86.. GTS |
FB, W/ Sports Seat, Blue |
71074-1A831-04 |
1 |
|
8608- |
AE86.. GTS |
FB, Black |
71074-1E110-01 |
1 |
|
8608- |
AE86.. GTS |
FB, Blue |
71074-1E110-04 |
1 |
71081S
Cover Sub-Assy, Front Seat Back, Side RH
|
Prod.
Date |
Model |
Description |
Part
Number |
Qty. |
|
8408-8508 |
AE86.. GTS |
Deep Maroon |
71081-12060-02 |
2 |
|
8408-8508 |
AE86.. GTS |
Grey |
71081-12060-03 |
2 |
71082S
Cover Sub-Assy, Front Seat Back, Side LH
|
Prod.
Date |
Model |
Description |
Part
Number |
Qty. |
|
8408-8508 |
AE86.. GTS |
Deep Maroon |
71082-12040-02 |
2 |
|
8408-8508 |
AE86.. GTS |
Grey |
71082-12040-03 |
2 |
71100S
Seat Assy. Front RH
|
Prod.
Date |
Model |
Description |
Part
Number |
Qty. |
|
8508-8608 |
AE86.. GTS |
FB, Black |
71050-1A260-01 |
1 |
|
8508-8608 |
AE86.. GTS |
FB, Blue |
71050-1A260-04 |
1 |
|
8608- |
AE86.. GTS |
FB, Black |
71050-1A261-01 |
1 |
|
8608- |
AE86.. GTS |
FB, Blue |
71050-1A261-04 |
1 |
71158S Frame, Front Seat Back, Upper RH
|
Prod.
Date |
Model |
Description |
Part
Number |
Qty. |
|
8408-8508 |
AE86.. GTS |
|
71158-12060- |
2 |
|
8508- |
AE86.. GTS |
|
71158-20130- |
2 |
71159S Frame, Front Seat Back, Upper LH
|
Prod.
Date |
Model |
Description |
Part
Number |
Qty. |
|
8408-8508 |
AE86.. GTS |
|
71159-12040- |
2 |
|
8508- |
AE86.. GTS |
|
71159-20080- |
2 |
71200S
Seat Assy. Front LH
|
Prod.
Date |
Model |
Description |
Part
Number |
Qty. |
|
8508-8608 |
AE86.. GTS |
FB, Black |
71020-1E650-01 |
1 |
|
8508-8608 |
AE86.. GTS |
FB, Blue |
71020-1E650-04 |
1 |
|
8608- |
AE86.. GTS |
FB, Black |
71020-1E651-01 |
1 |
|
8608- |
AE86.. GTS |
FB, Blue |
71020-1E651-04 |
1 |
71511S
Pad Front Seat Cushion, RH
|
Prod.
Date |
Model |
Description |
Part
Number |
Qty. |
|
8408-8508 |
AE86.. GTS |
|
71511-12460- |
1 |
71512S
Pad Front Seat Cushion, LH
|
Prod.
Date |
Model |
Description |
Part
Number |
Qty. |
|
8408-8508 |
AE86.. GTS |
|
71511-12460- |
1 |
71551S
Pad Front Seat Back, RH
|
Prod.
Date |
Model |
Description |
Part
Number |
Qty. |
|
8408-8508 |
AE86.. GTS |
|
71551-12420- |
1 |
|
8508- |
AE86.. GTS |
|
71551-12520- |
1 |
